The key steps to ensure network stability

In the industrial sector, industrial-grade 3G/4G wireless routers play a crucial role in data transmission. When network issues arise or maintenance is required, restarting the router is often one of the effective solutions. The following is a detailed introduction on how to restart this type of router.


Why restart industrial-grade 3G/4G wireless routers

After long-term operation, industrial-grade 3G/4G wireless routers may encounter problems such as cache accumulation, connection interruption, and slowed network speed. This might be caused by electromagnetic interference in industrial environments, system resource occupation due to large amounts of data transmission, or fluctuations in network signals, among other reasons. Restarting the router can clear the cache, re-establish the network connection, and restore the router to its best working condition, thereby ensuring the stable operation of the industrial network.


Preparations before restarting

• Backup configuration files: Log in to the router's management interface, find the configuration file backup option, download the current router configuration file and save it to your local device. In this way, after a restart, if there is a loss of configuration, it can be restored quickly.

• Record important information: including the login account and password of the router, the set network parameters (such as IP address, subnet mask, gateway, DNS server, etc.) and the information of the connected devices, etc.


Restart method

• Hardware restart
  Find the power interface: Industrial-grade 3G/4G wireless routers usually have a dedicated power interface, which could be a DC power interface or a power over Ethernet (PoE) interface.
  Cut off the power supply: Unplug the power adapter from the router, or in the case of PoE power supply, turn off the power of the corresponding port on the PoE switch. If the router is battery-powered, remove the battery.
  Wait for a moment: It is recommended to wait for 3 to 5 minutes to allow the capacitors inside the router to discharge and ensure that all circuits have completely stopped working.
  Reconnect the power supply: Plug the power adapter back into the router or reinstall the battery and turn on the power of the PoE switch port. Observe the indicator lights of the router. Usually, the power indicator light will light up first, and then the other indicator lights will flash or remain on in a certain order, which indicates that the router is starting up. Wait for the indicator light to stabilize, which indicates that the router has successfully restarted.

• Software restart
  Log in to the management interface: Open a browser and enter the management IP address of the router in the address bar. In the pop-up login interface, enter the correct username and password to log in.
  Find the restart option: In the router's management interface, you can usually find buttons for similar functions such as "Restart Router" or "System Restart" in menu options like "System Settings", "Device Management", or "Tools".
  Confirm restart: After clicking the "Restart Router" button, the system may pop up a confirmation prompt box, indicating that the restart operation may cause network interruption and other information. Click the "OK" button, and the router will start to restart automatically.

Check and Settings after restart

• Check the status of indicator lights: Confirm whether the power indicator light, network connection indicator light (such as WAN port, LAN port indicator light), 3G/4G signal indicator light, etc. are normally lit. If any indicator light is abnormal, it may indicate that there is a fault with the router or a connection issue, and further investigation is needed.

• Log in to the management interface to check the configuration: Log in to the router management interface again and check whether all network configurations are correct, such as whether the IP address, subnet mask, gateway, DNS server, etc. are consistent with the previous Settings. If necessary, you can upload the previously backed-up configuration file for restoration.

• Test network connection: Use industrial devices or computers connected to this router to try to access the Internet or other devices in the industrial network, and check if the network connection is normal and if data transmission is stable.


In conclusion, mastering the correct method to restart industrial-grade 3G/4G wireless routers is crucial for ensuring the stable operation of industrial networks. During the restart process, strictly follow the operation steps to avoid equipment damage or data loss due to improper operation. Regularly or on demand, restarting routers can effectively solve network problems and enhance the efficiency and reliability of industrial production.
